Reactors

Detuned reactors are connected in series with power factor correction capacitors. The reactor stops harmonic resonance and protects the capacitor from harmonic overload. Its percentage, for example 7%, sets the tuning point below the main harmonics. Detuned reactors are used in APFC panels in installations with drives, UPS systems, LED lighting and other non-linear loads. The reactor’s kVAR and voltage are matched to the capacitor step it serves, and each listing gives the winding material. This category lists L&T reactors by kVAR, voltage, tuning percentage and winding, each with its catalogue number. If you are building a detuned panel, check the step size of each capacitor and choose a reactor of the same kVAR and voltage.
Questions
Why use a reactor with a capacitor?
It stops harmonic resonance and protects the capacitor from harmonic overload.
What does the percentage mean?
It sets the tuning point below the main harmonics.
How do I choose a reactor?
Match its kVAR and voltage to the capacitor step.
Can I collect or get delivery in Qatar?
Yes. Collect from our warehouse at Building 37, Zone 91, Street 2043, Aba Salil Area, Al Bahya, or ask for delivery in Qatar. Call +974 4485 0110.
Supplying Qatar with same-day delivery, and Saudi Arabia, UAE, Bahrain, Kuwait and Oman by road. See GCC delivery

Showing all 2 results
