Air Circuit Breakers (ACBs)

Air circuit breakers (ACBs) handle the highest currents in low-voltage switchboards, above the range of MCCBs. They are used as the main incomer of a low-voltage main distribution board, as transformer and generator incomers, and for bus couplers and large outgoing circuits. An ACB has an electronic trip unit with adjustable protection settings, which are coordinated with the downstream breakers. Fixed and draw-out versions exist; a draw-out ACB racks out for maintenance. ACBs can be manually or electrically operated. This category lists LK air circuit breakers by current rating, poles, breaking capacity, frame and version code, each with its catalogue number. Send us your switchboard drawing or the existing breaker details and we will confirm the matching configuration before you order.

Questions

Where is an ACB used?

Where current is above the MCCB range, such as a main incomer.

What is a draw-out ACB?

One that racks out of its cradle for maintenance.

Can you check the configuration for me?

Yes. Send us your drawing or existing breaker details.

Can I collect or get delivery in Qatar?

Yes. Collect from our warehouse at Building 37, Zone 91, Street 2043, Aba Salil Area, Al Bahya, or ask for delivery in Qatar. Call +974 4485 0110.
